SJT (Geo) for geothermal production hot water
SJT (Geo) for geothermal production hot water
The simple yet effective hot water pump for geothermal
- Maximum achievable output flow for 12″ nominal bowl diameter (externally machined to 11 5/8″)
- Increased design temperature
- Pump shaft diameter 2 3/16″ in 17-4 PH H1150
- Pump shaft section lengths limited to 6.1 m (20 ft)
- Geothermal production hot water
- Shallow wells
- Designed for variable speed drive motors up to 2,200 rpm
- Extended endplay of bowls and impellers up to 5½”
- Simplified maintenance (assembly and disassembly)
- Impeller fixation to limit shaft upwards and downwards travel
- Bowl and suction case bearings with straight grooves
