Hopper feed pump Type KL-R Triplex
KL-R Triplex
Hopper feed pump Type KL-R Triplex
Pumps of the WANGEN KL-R Triplex series impress with their consistent dosing option, as an intermittent input is compensated by the buffer volume in the collecting container. No bridge building. The small space requirement and large receiving vessel are a result of the low construction and the large volume of the container. The best pump for dewatered sludge in waste water treatment plants. Highest robust design quality, what WANGEN pumps are well known for.
Very robust pump, ideal for pumping dewatered sewage sludge and therefore ideally suited for use in the sludge to energy sector. Developed for extra long lifespan.
Benefits and Characteristics
- buffer volume up to 10 m³ possible
- modular design for high flexibility and short downtimes for maintenance and repairs
- constant metering because the discontinuous input is compensated by buffer volume in the collecting container
- unattended operation possible
- excellent metering, important for dryer and incinerator operation
- easy to maintain thanks to large cleaning openings
- low-pulsation, continuous conveyance independent of pressure and viscosity
- optimum service life even with difficult media
- high operational reliability
- high pressure performance
- high dosing accuracy, also at low speed
- low Life Cycle Costs
- low construction with large container volume
- little space required, with large collecting container
The WANGEN KL-R Triplex series is able to convey media from chamber filter presses, screen belt presses or decanters to dryers, silos or storage areas, or other feeding jobs.
- from chamber filter presses
- to dryers
- to silos
- to storage areas
- for other feeding jobs
- from screen belt presses
- from decanters
- enlargement possible with add-on funnel
- continuous flow rates at high counterpressure up to 48 bar
- robust bearing pedestal with close-coupled drive and self-centering of the drive
- flexible drive selection
- fully developed, robust universal joint with pre-feeding screw
- wear-protected, robust universal joint with feeding screw
- collecting container optionally in three standard sizes (1m³/h – 10m³/h), special sizes on request
| Output |
0 – 80 m³/h (at 25 – 100 rpm) |
| Dry substance Content |
max. 45% |
| Free ball passage |
up to 121 mm |
